MP1495
High Efficiency 3A, 16V, 500kHz Synchronous Step Down Converter
DC/DC Full circuit analysis
Specification
| Part number | MP1495 |
|---|---|
| Manufacturer | MPS |
| Device type | DC/DC |
| Description | High Efficiency 3A, 16V, 500kHz Synchronous Step Down Converter |
| Analysis depth | Full circuit analysis |
| Report contents | Brief Report+Full CA |
What you receive
Cadence-compatible schematics
Compatible with Cadence Composer — edit it or convert to a netlist for simulation (simulation itself is not included).
Hierarchical PDF report
A PDF laid out by circuit hierarchy, readable on any platform, with die photo, device summary and architecture list.
This report comes from a Non-Exclusive commission and can be supplied to others. Exclusive commissions are never resold and therefore never appear in this library.
